- Products description -
100G OTN is compact 1U chassis 100G OTN Muxponder , adopt industry-leading chip technology , Complies with international ITU-T G.709, G.798, etc standards .
This equipment supports 10-port 10G customer-side interfaces and 1-port 100G system-side interfaces. It is suitable for optical transmission network applications in metropolitan area access and metropolitan area convergence.
Characteristics:
characteristics | Description |
Chassis size(Height*Width *Depth) | 440mm*350mm*44mm |
Power supply | 1＋1 power supply back up AC input :100~240V, 47~63Hz DC input : -40V~ -72V |
Maximum power consumption | 130W （Coherent color light CFP） 110W （White light CFP） |
Client side interface | 10 x10G SFP+ port（10GE LAN/WAN，STM-64/OC-192， FC8G，OTU2，OTU2e |
System side interface | 1 x100G CFP port （support coherent color light CFP，4x25G DWDM CFP or white light CFP）； 10G SFP+ port base on DWDM/CWDM |
Working environment | Working temperature: 0°C～45°C Storage temperature: -40°C to 70°C Relative humidity: 10% to 90%, non-condensing |
Specification
Specification | Description |
System-side signals and multiplexing structure | 100G grey CFP: OTU4 <-> ODU4 <-> ODU2 or ODU2e or ODUflex 100G DWDM CFP: OCh <-> OTU4 <-> ODU4 <-> ODU2 or ODU2e or ODUflex 10G grey SFP+: OTU2/OTU2e <-> ODU2/ODU2e 10G WDM SFP+: OCh <-> OTU2/OTU2e <-> ODU2/ODU2e |
Client side signaling and mapping | OC-192/STM-64 (via AMP or BMP) <-> ODU2 10GBASE-R (via BMP) <-> ODU2e 10GBASE-R (via GFP-F) <-> ODU2 10GBASE-R (via GFP-F extended payload with preamble) <-> ODU2 FC8G (via BMP) <->ODUflex (HW ready) |
100G port FEC mode | 100G OTU4: G.709 Regular FEC 100G coherent OCh: Soft-Decision FEC |
10G port FEC mode | Regular FEC (G.709) I.4 Super FEC (G.975.1) I.7 Super FEC (G.975.1) |
In-band management | GCC0 on OTU4 GCC1 or GCC2 or GCC1+2 on ODU4 GCC0 on OTU2/2e GCC1 or GCC2 or GCC1+2 on ODU2/2e |
Out-of-band management | Management Ethernet port |
Transmission protection | SNC/N SNC/I |
Network Management System | SNMP based NMS |
|
Products damaged due to human or non-use of other causes of improper,we promises one year warranty and lifetime maintenance,but the unauthorized disassembly equipment caused damage is not covered under warranty and returned within range. |
|
Under normal use,if there are product quality problems,or not work normally,we provide free repair or replacement service within one year;Within three years more than one year,we provide to collect the material cost,maintenance free. Repair warranty period of three years from the freight borne by each of the parties.After three years of warranty,the material cost,maintenance,freight(refers to the product of the two-way shipping to and from)shall be borne by the user. |
|
We promise that the product we provide can meet the performance requirements of users , and it is supplied by the user's sample request. |
