- Product Description -
Convergence and diversion equipment are also called traffic collectors, tap devices, network shunts, shunts, mirror switches, etc. their functions: they are connected in series or in parallel in the network to collect network traffic data, which can be copied to multiple ports and converged to individual ports to provide back-end platform applications that need to analyze and monitor network content. Or you can filter out the data desired by the application platform according to certain rules.
- Features -
1.48 channels 10GE + 6 channels 100ge optical interface, support SFP + / qsfp28 pluggable optical module and LC optical fiber terminal.
2. Support rates of 10GBASE-R, 40gbase - R4 and 100gbase-lr4, and wavelengths of 850 / 1310 / 1550nm.
3. Support single fiber receiving or single fiber sending of optical module.
4. The optical interface can be configured with input or output at will.
5. It can monitor the output flow at full load, with a total monitoring flow of 1080gbps.
6. Support the data aggregation output of multiple ports, and also support the data of one or more ports to be copied to multiple monitoring ports for output at the same time.
7. Support VLAN and QinQ packet identification and filtering, MPLS label stripping, VLAN field stripping, replacement, addition and other operations.
8. Support load balancing and shunting function, and support blacklist mode or whitelist mode.
9. Support a variety of network management modes, including console and SSH command line mode and Web Chinese and English network management mode.
10. Support remote online upgrade of system software.
|
