: 1X4 MEMS Optic switch

Category：XYT-OSW-MEMS-XX
Code：MEMS Switch

Chat Online

Features
Product
Specification
Sale service
Technical Support

- Products description -

Sharetop(XYT-TECH) MEMS OSW is based on micro-electro-mechanical system (MEMS) technology, which achieved low insertion loss and highly repeatability by rotating the mirror of MEMS chip. MEMS OSW is mainly used in optical cross and connection (OXC) system, optical add/drop system, measure instrument system and optical signal monitoring system.The products are Telcordia GR-1073-CORE qualified, and RoHS ompliant.

- Product Features -

• High Reliability

• Intrinsic tolerance to ESD

- Product Specification -

• Channel Blocking

• Configurable Add/Drop

• System Monitoring

• Instrumentation

Specification

Parameters		Unit	Value
Wavelength		nm	1310/1550
Insertion Loss	Without connector	dB	≤1.0
Return Loss		dB	≥50
Repeatability		dB	≤0.1
Crosstalk		dB	≥50
Polarization Dependence Loss		dB	≤0.15
Wavelength Dependence Loss		dB	≤0.3
Temperature Dependence Loss		dB	≤0.3
Switch Time		ms	≤30
Durability		cycle	≥1x109
Maximum optical Power		mW	≤500
Switch Mode			Non-Latching
Power Voltage		V	5
Power Consumption		mW	≤500
Operation Temperature		°C	-5~70
Storage Temperature		°C	-40~85
Dimension		mm	(L)68x (W)30x(H)13

PINS:

Pin Number	Name	Inout/Ouput	Level	Function
1	NC	NO connector
2	VCC	Power supply		+(5.0±5%)V Power Supply Max 100mA
3	Strobe	Input	LVTTL	For TTL Mode:Falling edge active , latches D3-D0 inputs
				For I Mode:Not used
4	GND	Power supply ground		Power supply ground
5	D0/A0	Input	LVTTL	For TTL Mode:Data 0 input
				For I Mode:A0 for I address
6	I Data	Inout/Ouput	LVTTL	For TTL Mode:Not used
				For I Mode:I interface Data
7	I Clock	Input	LVTTL	For TTL Mode:Not used
				For I Mode:I interface Data
8	I/F Mode	Input	LVTTL	Select TTL or I mode for TTL mode for I mode
9	D2/A2	Input	LVTTL	For TTL Mode:Data 2 input
				For I Mode:A2 for I address
10	/Done	Output	LVTTL	Optical switch done, low active
11	Case GND	Case ground		Case ground
12	D1/A1	Input	LVTTL	For TTL Mode:Data 1 input
				For I Mode:A1 for I address
13	D3/A3	Input	LVTTL	For TTL Mode:Data 3 input
				For I Mode:A3 for I address
